【案例】：南通|Legrand 罗格朗单相隔离变压器 0 442 64,160VA

▊ 概要

高思（GAOSSI^®）专业供应法国罗格朗（Legrand）品牌控制与信号变压器（control, signalling and safety isolation transformers open type single phase）0442系列044264（160VA, 230~400V ac输入,115V输出）等产品，应用在汽车、光伏、机床、冲床/压力机、车辆、钢铁、建筑、机械设备、电气设备、电子、通讯、医疗器械等行业。

—— ◇ ——

Legrand 罗格朗单相安全隔离变压器 0 442 64 160VA ,DIN安装 500X309

▣ BRIEF INTRODUCTION

单相隔离变压器
0442系列
044264
160VA,230~400V AC,115V

TRANSFORMATEUR COMMANDE ET SÉPARATION DES CIRCUITS CONNEXION VIS PRIMAIRE 230V À 400V, SECONDAIRE 115V~ À 230V~ – 160VA

▊ 属性

品名 NAME	型号 TYPE	系列 SERIES
控制与信号变压器（control, signalling and safety isolation transformers open type single phase）	044264	0442系列
品牌 BRAND	系别 COUNTRY	产地 ORIGIN
罗格朗（Legrand）	法国	法国

※ 提示：了解更多规格参数，可咨询客服。

▊ 客户

南通市某客户

▊ 实图

图1 LEGRAND 罗格朗单相隔离变压器 044264, 160VA实物展示 – 高思（GAOSSI®）原装进口正品保证库存现货

提示：了解更多系列型号，可咨询客服、参考产品目录或企业官网。

南通 | LEGRAND 罗格朗单相隔离变压器 044264，160VA

Nantong | LEGRAND Single-phase Isolation Transformer 044264, 160VA

一、项目背景

南通某船舶服务有限公司承接当地船舶企业的配套电气改造与成套项目，船舶机舱电控系统、信号监测设备对供电稳定性、电气安全性要求极高。船舶工况存在潮湿、电压波动、电气干扰强等问题，需要专用进口隔离变压器实现电气隔离，规避漏电、信号紊乱、设备故障等风险，保障船舶设备安全稳定运行。

Project Background

A ship service company in Nantong undertakes supporting electrical renovation and complete set projects for local shipbuilding enterprises. The ship cabin electronic control systems and signal monitoring equipment have extremely high requirements for power supply stability and electrical safety. The marine operating environment features high humidity, voltage fluctuation and strong electrical interference. A special imported isolation transformer is required for electrical isolation to avoid electric leakage, signal disorder and equipment failure, ensuring the safe and stable operation of marine equipment.

二、产品选型

结合终端船舶项目图纸规范与严苛的现场工况，客户指定选用法国原装进口 LEGRAND 罗格朗 044264 单相隔离变压器（160VA）。该产品隶属于罗格朗0442系列控制与信号隔离变压器，遵循IEC、EN官方标准生产，核心参数精准适配工控及船舶配套场景：支持230~400V宽幅输入、115/230V双档位输出，采用B级绝缘材质、绕组间绝缘电压达4510V，具备IP2X防护等级与IK04抗冲击等级。设备标配标准DIN导轨安装结构、螺丝接线端子，体积紧凑，可直接集成于标准电控柜，适配船舶设备50/60Hz工频运行需求，完全满足船舶电气设备长期连续运行的严苛规范。

Product Selection

In accordance with the drawing specifications and strict on-site working conditions of the terminal ship project, the customer adopted the original French imported LEGRAND 044264 single-phase isolation transformer (160VA). Belonging to the LEGRAND 0442 series of control and signal isolation transformers, it is manufactured in compliance with official IEC and EN standards. It supports wide-range input of 230~400V and dual output gears of 115/230V, with Class B insulation and inter-winding insulation voltage of 4510V, as well as IP2X protection grade and IK04 impact resistance grade. Equipped with standard DIN rail mounting structure and screw wiring terminals, the compact device can be directly integrated into standard electric control cabinets, adapting to the 50/60Hz power frequency operation of marine equipment and fully meeting the strict specifications for long-term continuous operation of marine electrical equipment.

三、应用效果

该变压器投入船舶电控系统运行后，整体工况稳定可靠，凭借6.94%标准短路电压参数，实现精准电气隔离，有效滤除船舶机舱潮湿环境下的电网杂波、电气噪声与电压波动干扰，彻底规避弱电控制回路漏电、信号紊乱、设备误动作等问题。产品支持最高50℃环境温度无降额连续运行，运行温升低、静音无噪，无需改造原有船舶标准控制柜结构，安装便捷、适配性强，完全符合EN 61558系列、EN 60204-1、EN 61439-1等行业标准，顺利通过终端船舶企业严格的设备报验与验收。

Application Results

After being put into operation in the marine electronic control system, the transformer runs stably and reliably. With a standard short-circuit voltage of 6.94%, it achieves precise electrical isolation, effectively filtering grid clutter, electrical noise and voltage fluctuation interference in the humid marine cabin environment, and completely avoiding electric leakage, signal disorder and equipment misoperation of weak current control loops. It supports continuous operation without derating at a maximum ambient temperature of 50℃, featuring low temperature rise and quiet operation. It requires no modification to the original standard marine control cabinet with simple installation and strong compatibility. Complying with EN 61558 series, EN 60204-1, EN 61439-1 and other industrial standards, it has successfully passed the strict equipment inspection and acceptance of the terminal ship enterprise.

四、典型优势

• 160VA额定容量（IEC标准）、140VA额定容量（UL标准），适配船舶弱电控制、信号监测回路供电隔离；
• 法国原装进口，罗格朗原厂0442系列正品，符合IEC、EN、UL、CSA多重国际标准；
• 高绝缘性能设计，绕组间绝缘电压4510V，B级绝缘，耐受船舶复杂温湿度工况；
• 230~400V宽幅交流输入、115/230V双路输出，适配船舶电网电压波动场景；
• 标准DIN导轨安装+螺丝接线端子，适配船舶成套电控柜标准化集成；
• IP2X防护、IK04抗冲击，50℃高温无降额运行，适配船舶全天候连续作业；
• 内置双耦合条配置，短路电压参数稳定，抗干扰、防漏电性能优异，满足船舶报验规范。

Key Advantages

• 160VA rated capacity (IEC standard) / 140VA rated capacity (UL standard), suitable for power isolation of marine weak current control and signal monitoring loops
• Original imported from France, genuine LEGRAND 0442 series product, compliant with multiple international standards including IEC, EN, UL and CSA
• High insulation performance design with 4510V inter-winding insulation voltage and Class B insulation, adapting to complex temperature and humidity working conditions of ships
• Wide-range AC input of 230~400V and dual output of 115/230V, adapting to marine grid voltage fluctuation scenarios
• Standard DIN rail mounting and screw wiring terminals for standardized integration of marine complete electric control cabinets
• IP2X protection and IK04 impact resistance, supporting non-derating operation at 50℃, suitable for all-weather continuous marine operation
• Equipped with dual coupling bars, stable short-circuit voltage parameters, excellent anti-interference and anti-leakage performance, meeting marine inspection specifications

五、总结

本次南通船舶配套项目，严格采用罗格朗原厂044264官方标准产品，依托产品精准的电气参数、严苛的国际认证与适配船舶工况的结构设计，高效解决了船舶电控系统供电隔离、抗干扰、安全防护等核心难题。产品各项性能完全契合高思官网及罗格朗法国总部公示的技术规范，现场运行稳定、验收通过率高，充分印证了罗格朗原装进口隔离变压器在船舶工业配套场景的专业性与可靠性，为后续船舶电气成套项目提供标准化选型参考。

Conclusion

In this Nantong marine supporting project, the official standard LEGRAND 044264 product was strictly adopted. Relying on its accurate electrical parameters, strict international certifications and structural design adapted to marine working conditions, it efficiently solved the core problems of power isolation, anti-interference and safety protection of marine electronic control systems. All product performances fully conform to the technical specifications published on the GAOSSI official website and LEGRAND French headquarters. With stable on-site operation and high acceptance rate, it fully verifies the professionalism and reliability of original imported LEGRAND isolation transformers in marine industrial supporting scenarios, providing a standardized selection reference for subsequent marine electrical complete set projects.

—— ✤ ——
