▊ 概要
高思（GAOSSI®）专业供应法国施耐德（Schneider Electric）品牌接触器（Contactor）TeSys Giga系列LC1G2654EHEN等产品，应用于工业自动化、楼宇电气、数据中心、PLC控制系统、机床、冲床、电梯、包装机械等领域。
—— ◇ ——
▣ BRIEF INTRODUCTION
- 交流接触器
- TeSys Giga系列
- LC1G2654EHEN
- 4P
※ Pictures shown are for illustrative purposes only.
▊ 属性
| 品名 NAME | 型号 TYPE | 系列 SERIES |
| 接触器（Contactor） | LC1G2654EHEN | TeSys Giga系列 |
| 品牌 BRAND | 系别 COUNTRY | 产地 ORIGIN |
| 施耐德电气（Schneider Electric） | 法国 | — |
▊ 型号
高思（GAOSSI®）专业供应以下系列型号产品：
☑ 系列型号
• 略
说明：以上系列型号源自于产品目录或企业官网。如有发生变更，恕不另行通知，具体可参考官网、产品目录或官方通告。
☑ 型号说明
【技術】：Schneider施耐德 交流接触器 TeSys Giga系列型号构成详解-GAOSSI 高思
☑ 型号示例
• 略
提示：了解更多系列型号，可咨询客服、参考产品目录或企业官网。
▊ 规格
☑ 规格参数
| Range | TeSys |
|---|---|
| Range of Product | TeSys Giga |
| Product or Component Type | Contactor |
| Device short name | LC1G |
| Contactor application | Power switching |
| Utilisation category | AC-3 AC-3e AC-1 AC-5a AC-5b AC-6a AC-6b DC-1 DC-3 DC-5 |
| Poles description | 4P |
| [Ue] rated operational voltage | <= 1000 V AC 50/60 Hz <= 460 V DC |
| [Ie] rated operational current | 265 A (at <140 °F (60 °C)) at <= 440 V AC-3 385 A (at <104 °F (40 °C)) at <= 1000 V AC-1 |
| [Uc] control circuit voltage | 48…130 V AC 50/60 Hz 48…130 V DC |
| Control circuit voltage limits | Operational: 0.8 Uc Min…1.1 Uc Max (at <140 °F (60 °C)) Drop-out: 0.1 Uc Max…0.45 Uc Min (at <140 °F (60 °C)) |
| [Uimp] rated impulse withstand voltage | 8 kV |
|---|---|
| Overvoltage category | III |
| [Ith] conventional free air thermal current | 385 A (at 104 °F (40 °C)) |
| Rated breaking capacity | 2380 A at 440 V |
| [Icw] rated short-time withstand current | 2.2 kA – 10 s 1.23 kA – 30 s 0.95 kA – 1 min 0.62 kA – 3 min 0.48 kA – 10 min |
| Associated fuse rating | 315 A aM at <= 440 V for motor 250 A aM at <= 690 V for motor 400 A gG at <= 690 V 450 A UL Type J at <= 600 V |
| Average impedance | 0.000144 Ohm |
| [Ui] rated insulation voltage | 1000 V |
| Power dissipation per pole | 20 W AC-1 – Ith 385 A 11 W AC-3 – Ith 265 A |
| Compatibility code | LC1G |
| Pole contact composition | 4 NO |
| Auxiliary contact composition | 1 NO + 1 NC |
| Irms rated making capacity | 3320 A at 440 V |
| Coil technology | Built-in bidirectional peak limiting |
| Safety reliability level | B10d = 400000 cycles contactor with nominal load EN/ISO 13849-1 B10d = 3000000 cycles contactor with mechanical load EN/ISO 13849-1 |
| Mechanical durability | 8 Mcycles |
| inrush power in VA (50/60 Hz, AC) | 780 VA |
| inrush power in W (DC) | 695 W |
| hold-in power consumption in VA (50/60 Hz, AC) | 17.6 VA |
| hold-in power consumption in W (DC) | 7.8 W |
| Operating time | 40…70 ms closing 15…50 ms opening |
| Maximum operating rate | 600 cyc/h AC-3 600 cyc/h AC-3e 300 cyc/h AC-1 |
| Connections – terminals | Power circuit: bar 2 – busbar cross section: 32 x 10 mm Power circuit: lugs-ring terminals 1 0.3 in² (185 mm²) Control circuit: push-in 1 0.0003…0.004 in² (0.2…2.5 mm²) – cable stiffness: solid stranded without cable end Control circuit: push-in 1 0.0004…0.004 in² (0.25…2.5 mm²) – cable stiffness: flexible with cable end Control circuit: push-in 2 0.0008…0.002 in² (0.5…1.0 mm²) with cable end Control circuit: push-in 0.001…0.004 in² (0.75…2.5 mm²) – cable stiffness: solid stranded without cable end Control circuit: push-in 0.001…0.004 in² (0.75…2.5 mm²) – cable stiffness: flexible with cable end |
| Connection pitch | 1.8 in (45 mm) |
| Mounting Support | Plate |
| Standards | EN/IEC 60947-4-1 EN/IEC 60947-5-1 UL 60947-4-1 CSA C22.2 No 60947-4-1 JIS C8201-4-1 JIS C8201-5-1 UL 60335-1 UL 60335-2-40:Annex JJ |
| Product Certifications | CB Scheme CCC cULus EAC CE UKCA EU-RO-MR by DNV-GL |
| Tightening torque | 309.8 lbf.in (35 N.m) |
| Height | 8.9 in (225 mm) |
| Width | 7.3 in (185 mm) |
| Depth | 8.9 in (226 mm) |
| Net Weight | 18.3 lb(US) (8.3 kg) |
| IP degree of protection | IP2X front face with shrouds IEC 60529 IP2X front face with shrouds VDE 0106 |
|---|---|
| Ambient Air Temperature for Operation | -13…140 °F (-25…60 °C) |
| Ambient Air Temperature for Storage | -76…176 °F (-60…80 °C) |
| Mechanical robustness | Vibrations 5…300 Hz 2 gn contactor open Vibrations 5…300 Hz 4 gn contactor closed Shocks 10 gn 11 ms contactor open Shocks 15 gn 11 ms contactor closed |
| color | Dark grey |
| Protective treatment | TH |
| Permissible ambient air temperature around the device | -40…158 °F (-40…70 °C) at Uc |
| Category | US10I1222329 |
|---|---|
| Discount Schedule | 0I12 |
| GTIN | 3606481922069 |
| Returnability | Yes |
| Country of origin | CN |
| Unit Type of Package 1 | PCE |
|---|---|
| Nbr. of units in pkg. | 1 |
| Package 1 Height | 10.236 in (26.000 cm) |
| Package 1 Width | 12.205 in (31.000 cm) |
| Package 1 Length | 12.598 in (32.000 cm) |
| Package weight(Lbs) | 20.029 lb(US) (9.085 kg) |
| Unit Type of Package 2 | S06 |
| Number of Units in Package 2 | 4 |
| Package 2 Height | 29.528 in (75.000 cm) |
| Package 2 Width | 23.622 in (60.000 cm) |
| Package 2 Length | 31.496 in (80.000 cm) |
| Package 2 Weight | 102.162 lb(US) (46.340 kg) |
☑ 外形规格
说明：以上规格参数源自于产品目录或企业官网。如有发生变更，恕不另行通知，具体可参考官网、产品目录或官方通告。
▊ 特点
• 旨在满足苛刻应用的需求，内置先进功能和特性。
Designed to meet needs of demanding applications built-in with advanced features and functionalities.
• 参考数量少，易于选择，选择意味着库存更少。
Less number of references, simple to select, choose means less inventory.
• 电缆记忆套件，通过快速维护节省停机时间并提高生产力。
Cable memory kit, saves downtime and improves productivity by performing quick maintenance.
• 过载继电器内置接地故障保护、相不平衡/故障保护及单相负载保护。
Overload relay built in ground fault protection, phase imbalance/failure protection and protection of single phase loads.
• 线圈设计以降低能耗并扩展电压带宽。
Coil designed for less energy consumption and wider voltage band-width.
▊ 应用
• 应用于工业自动化、楼宇电气、数据中心、PLC控制系统、机床、冲床、电梯、包装机械等领域。
