▊ 概要
高思（GAOSSI®）专业供应法国施耐德（Schneider Electric）品牌接触器（Contactor）TeSys F系列LC1F630等产品，应用于工业自动化、楼宇电气、数据中心、PLC控制系统、机床、冲床、电梯、包装机械等领域。
—— ◇ ——
▣ BRIEF INTRODUCTION
- 接触器
- TeSys F系列
- LC1F630
- Discontinued on: Jan 31, 2024
※ Pictures shown are for illustrative purposes only.
▊ 属性
| 品名 NAME | 型号 TYPE | 系列 SERIES |
| 接触器（Contactor） | LC1F630 | TeSys F系列 |
| 品牌 BRAND | 系别 COUNTRY | 产地 ORIGIN |
| 施耐德电气（Schneider Electric） | 法国 | — |
▊ 型号
高思（GAOSSI®）专业供应以下系列型号产品：
☑ 系列型号
• 略
说明：以上系列型号源自于产品目录或企业官网。如有发生变更，恕不另行通知，具体可参考官网、产品目录或官方通告。
☑ 型号说明
• 略
☑ 型号示例
• 略
提示：了解更多系列型号，可咨询客服、参考产品目录或企业官网。
▊ 规格
☑ 规格参数
| Range | TeSys |
|---|---|
| Product name | TeSys F |
| Product or Component Type | Contactor |
| Device short name | LC1F |
| Contactor application | Resistive load Motor control |
| Utilisation category | AC-4 AC-1 AC-3 |
| Poles description | 3P |
| power pole contact composition | 3 NO |
| [Ue] rated operational voltage | <= 1000 V AC 50/60 Hz <= 460 V DC |
| [Ie] rated operational current | 1000 A 104 °F (40 °C)) <= 440 V AC AC-1 630 A 131 °F (55 °C)) <= 440 V AC AC-3 |
| Motor power kW | 335 kW at 380…400 V AC 50/60 Hz (AC-3) 375 kW at 415 V AC 50/60 Hz (AC-3) 400 kW at 440 V AC 50/60 Hz (AC-3) 400 kW at 500 V AC 50/60 Hz (AC-3) 450 kW at 1000 V AC 50/60 Hz (AC-3) 200 kW at 220…240 V AC 50/60 Hz (AC-3) 450 kW at 660…690 V AC 50/60 Hz (AC-3) 100 kW at 400 V AC 50/60 Hz (AC-4) |
| [Uc] control circuit voltage | 48…1000 V AC 40…400 Hz with LX1/LX9 coil 48…440 V DC with LX4 coil |
|---|---|
| [Uimp] rated impulse withstand voltage | 8 kV |
| Overvoltage category | III |
| [Ith] conventional free air thermal current | 1000 A (at 104 °F (40 °C)) 1250 A |
| Irms rated making capacity | 6300 A AC conforming to IEC 60947-4-1 |
| Rated breaking capacity | 5040 A conforming to IEC 60947-4-1 |
| [Icw] rated short-time withstand current | 5050 A 104 °F (40 °C) – 10 s 4400 A 104 °F (40 °C) – 30 s 3400 A 104 °F (40 °C) – 1 min 2200 A 104 °F (40 °C) – 3 min 1600 A 104 °F (40 °C) – 10 min |
| Associated fuse rating | 630 A aM at <= 440 V 1000 A gG at <= 440 V |
| Average impedance | 0.12 mOhm – Ith 1000 A 50 Hz |
| [Ui] rated insulation voltage | 1000 V IEC 60947-4-1 1500 V VDE 0110 group C |
| Power dissipation per pole | 120 W AC-1 48 W AC-3 |
| Control circuit voltage limits | Operational: 0.85…1.1 Uc AC 40…400 Hz with LX1/LX9 coil Drop-out: 0.25…0.5 Uc AC 40…400 Hz with LX1/LX9 coil Operational: 0.85…1.1 Uc DC with LX4 coil Drop-out: 0.2…0.35 Uc DC with LX4 coil |
| Heat dissipation | 20 W |
| Operating time | 40…80 ms closing with LX1/LX9 coil 100…200 ms opening with LX1/LX9 coil 60…70 ms closing with LX4 coil 40…50 ms opening with LX4 coil |
| Mounting Support | Plate |
| Standards | EN 60947-4-1 IEC 60947-4-1 IEC 60947-1 JIS C8201-4-1 EN 60947-1 |
| Product Certifications | ABS UL RINA DNV CSA CB LROS (Lloyds register of shipping) BV RMRoS UKCA |
| Connections – terminals | Power circuit bar 2 60 x 5 mm Power circuit bolted connection Control circuit screw clamp terminals 1 0.002…0.006 in² (1…4 mm²)flexible without cable end Control circuit screw clamp terminals 2 0.002…0.006 in² (1…4 mm²)flexible with cable end Control circuit screw clamp terminals 1 0.002…0.006 in² (1…4 mm²)flexible with cable end Control circuit screw clamp terminals 2 0.002…0.004 in² (1…2.5 mm²)solid without cable end Control circuit screw clamp terminals 1 0.002…0.006 in² (1…4 mm²) Control circuit screw clamp terminals 2 0.002…0.006 in² (1…4 mm²) |
| Tightening torque | Power circuit 513.3 lbf.in (58 N.m) Control circuit 10.6 lbf.in (1.2 N.m) |
| Mechanical durability | 5 Mcycles |
| Inrush power in VA | 1500…1730 VA, 40…400 Hz cos phi 0.9 (at 68 °F (20 °C))with LX1/LX9 coil 1420…1920 VA (at 68 °F (20 °C))with LX4 coil |
| Hold-in power consumption in VA | 20…25 VA, 40…400 Hz cos phi 0.9 (at 68 °F (20 °C))with LX1/LX9 coil 6.5…12.5 VA (at 68 °F (20 °C))with LX4 coil |
| Maximum operating rate | 1200 cyc/h 131 °F (55 °C) |
| Compatibility code | LC1F |
| IP degree of protection | IP20 front face with shrouds IEC 60529 IP20 front face with shrouds VDE 0106 |
|---|---|
| Protective treatment | TH |
| Ambient Air Temperature for Operation | 23…131 °F (-5…55 °C) |
| Ambient Air Temperature for Storage | -76…176 °F (-60…80 °C) |
| Permissible ambient air temperature around the device | -40…158 °F (-40…70 °C) |
| Operating altitude | 9842.52 ft (3000 m) without derating |
| Mechanical robustness | Vibrations contactor open2 Gn, 5…300 Hz Vibrations contactor closed4 Gn, 5…300 Hz Shocks contactor open6 Gn for 1/2 sine wave (11 ms) Shocks contactor closed15 Gn for 1/2 sine wave (11 ms) |
| Height | 12.0 in (304 mm) |
| Width | 12.2 in (309 mm) |
| Depth | 10.04 in (255 mm) |
| Net Weight | 41.006 lb(US) (18.6 kg) |
| Category | US10I1222336 |
|---|---|
| Discount Schedule | 0I12 |
| GTIN | 3389110122183 |
| Returnability | Yes |
| Country of origin | CZ |
| Unit Type of Package 1 | PCE |
|---|---|
| Nbr. of units in pkg. | 1 |
| Package 1 Height | 13.386 in (34.000 cm) |
| Package 1 Width | 13.386 in (34.000 cm) |
| Package 1 Length | 17.717 in (45.000 cm) |
| Package weight(Lbs) | 37.721 lb(US) (17.110 kg) |
| Unit Type of Package 2 | P06 |
| Number of Units in Package 2 | 4 |
| Package 2 Height | 29.528 in (75.000 cm) |
| Package 2 Width | 23.622 in (60.000 cm) |
| Package 2 Length | 31.496 in (80.000 cm) |
| Package 2 Weight | 169.624 lb(US) (76.940 kg) |
| Warranty (in months) | 18 |
|---|
☑ 外形规格
• 略
说明：以上规格参数源自于产品目录或企业官网。如有发生变更，恕不另行通知，具体可参考官网、产品目录或官方通告。
▊ 特点
• 后期选择无线圈
• 高耐用性：操作速率每小时1200次
• 高可靠性：环境耐受温度可达55°C
• 由于抽屉式线圈安装和丰富的附加模块选择，安装和维护简便
• 多种应用领域，拥有多种标准认证
▊ 应用
• 应用于工业自动化、楼宇电气、数据中心、PLC控制系统、机床、冲床、电梯、包装机械等领域。
